TP-Link
5-port Gigabit Multi-WAN Load Balance Router for SMB
5-port Gigabit Multi-WAN Load Balance Router for SMB
SKU:TL-ER5120
Low stock: 1 left
Shipping calculated at checkout.
Couldn't load pickup availability
- 64-bit dedicated dual-core processor and 2 Gbit DDRIII high-speed memory for outstanding performance
- Equipped with 1 Gigabit WAN port, 1 Gigabit LAN port, and 3 adaptable Gigabit WAN/LAN ports
- Load Balancing automatically selects the best route to the destination according to the load
- The captive portal provides convenient guest authentication while promoting your business
- Abundant security features including ARP Inspection, DoS Defense, URL/Keyword Domain Filter and Access Control
- Professional 4KV lightning protection keeps your investment safe1
| HARDWARE FEATURES | |
|---|---|
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, PPTP, L2TP |
| Interface | 1 Gigabit WAN port 3 Gigabit LAN/WAN ports 1 Gigabit LAN port |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
| Button | Reset Button |
| Power Supply | Internal Universal Power Supply AC100-240V~ 50/60Hz Input |
| Flash | 32MB |
| DRAM | DDRIII 256MB |
| LED | PWR, SYS, Link/Act, Speed, WAN |
| Dimensions ( W x D x H ) | 17.3 x 8.7 x 1.7 in.(440x220x44 mm) 19-inch Standard Rack-Mount Width, 1U Height |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 150K |
| NAT Throughput | 800Mbps |
| HARDWARE FEATURES | |
|---|---|
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, PPTP, L2TP |
| Interface | 1 Gigabit WAN port 3 Gigabit LAN/WAN ports 1 Gigabit LAN port |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m) |
| Button | Reset Button |
| Power Supply | Internal Universal Power Supply AC100-240V~ 50/60Hz Input |
| Flash | 32MB |
| DRAM | DDRIII 256MB |
| LED | PWR, SYS, Link/Act, Speed, WAN |
| Dimensions ( W x D x H ) | 17.3 x 8.7 x 1.7 in.(440x220x44 mm) 19-inch Standard Rack-Mount Width, 1U Height |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 150K |
| NAT Throughput | 800Mbps |
