Multi-Purpose Adaptor for IX Series

• Power Source: 802.3af PoE compliant
• Power Draw: Standby: 43 mA; Maximum: 135 mA
• Relay Output: Relays 1-4: Form C 24V AC/DC 500mA

                                 : Relays 5-10: Form A 24V AC/DC 500mA

• LAN: Ethernet (10BASE-T, 100BASE-TX)
• Protocols: IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS
• Encryption system: TLS1.0, TLS1.1, TLS1.2
• Port Security: IEEE 802.1X
• Operating Temp: 14° ~ 104°F (-10° ~ 50°C)
• Dimensions: 7-1/2" x 9-5/8" x 13/16"
• Weight: 1.39 lbs

• New features available for North America with a firmware update
• Program using the IX Series Support tool
• Powered over POE, no additional power supply required!
• 4 activation inputs, 10 relay outputs
• Line Supervision events from IX Series master can trigger a relay closure
• Activate with either relay output from IX series stations
